Massimo Warrior 800, 800cc 60HP, Electric, Liquid-Cooled, Four Stroke 2 Cylinder V-Twin
SINCE THESE ARE VERY BIG UNITS PLEASE ALLOW 3 TO 4 ADDITIONAL PROCESSING TIME
At Arlington PowerSports, we specialize in everything motorized that goes off-road. WeÂ’re a licensed dealer with years of experience and thousands of sales under our belts.
If you have questions or would like to know more about the Massimo Warrior 800, 800cc 60HP, Electric, Liquid-Cooled, Four Stroke 2 Cylinder V-Twin, give us a call at 1-817-649-7823 and weÂ’ll be happy to help.
4500 LB WINCH
Climb, tow or pull whatever you want, wherever you want.
HYDROLIC DUMP BED
For effortless hauling and dumping up to 500 lbs.
ON-DEMAND 4WD
Push-button, shaft drive with locking differential.
12.7 GALLON TANK
Electronic fuel injected four stroke 2 cylinder v-Twin engine.
Assembled in
the USA
1 year parts &
labor warranty
24/7 customer
service line
Built tough for every job
Engineered with a sturdy steel frame
Features
Electronic Power Steering
Warranty: 1 Year Parts & Labor
Battery: 12V 35AMP
Assembled in Texas, USA
Instrumentation: Digital Display, Speedometer, Odometer, Tachometer, Hour Meter, Gear Indicator, 4WD Indicator, Differential Lock Indicator, Trip Meter, Headlights (High/Low), Turn Signals, Fuel Gauge, Hi-Temp
Technical Specs
Dimensions
Vehicle Size (L x W x H): 131.5 in x 70 in x 77 in
Wheelbase: 91.5 in
Ground Clearance: 12.5 in
Cargo Bed (L x W x H): 42.5 in x 65.5 in x 10.25 in
Cargo Bed: Hydraulic Piston Dump
Towing Capacity: 1,500 lbs
Cargo Bed Capacity: 500 lbs
Fuel Capacity: 12.7 gallons
Seat Height: 34.5 in
Dry Weight: 1,830 lbs
Engine
Engine Type: Four Stroke 2 Cylinder V-Twin
Displacement: 800cc
Horsepower: 60 HP
Cooling: Liquid Cooled
Transmission/Final Drive: Automatic CVT P/R/N/L/H, Shaft Drive
Drive System: 2WD/4WD, Locking Differential
Fuel System: Electronic Fuel Injection (EFI)
Chassis
Front Suspension: Independent Dual A-Arm
Rear Suspension: Independent Dual A-Arm
Front Tires: AT 27 x 9-14
Rear Tires: AT 27 x 11-14
Front Brakes: Dual Ventilated Hydraulic Disk Brakes
Rear Brakes: Dual Ventilated Hydraulic Disk Brakes
Wheels: Aluminum
